In this case, cable connections may be made to Serial 1 on either the 10-pin PDQ Board Serial Communications Header, or the Docking Panel’s 10-pin right-angle Serial Header, or the Docking Panel’s Serial1 DB-9 Connector. In this case, cable connections may be made to Serial 1 at pins 5 and 6 of the PDQ Board’s 10-pin Serial Header , or pins 5 and 6 of the Docking Panel’s 10-pin right-angle Serial Header. The most common cable type is Cat 5e-UTP (unshielded twisted pair) which may work over shorter distances in less demanding applications with low EMI noise levels. Any of these conditions may generate an interrupt if the SPIE (SPI interrupt enable) bit in the SPCR control register is set. A FIFO is a First In/First Out buffer that can queue a burst of outgoing characters for transmission, or save a set of incoming characters until the host can read them.

The DWOM bit (port D wired-or mode) should always be set to 0. Setting DWOM to 1 takes away the processor’s ability to pull the Port D signals high unless there is a pull-up resistor on each bit of the port. There are surface-mount resistor pads on the Docking Panel to bring out the RS485 signals to the DB9 Serial 1 Connector. The mating 10-pin connectors that join the H6 header of the PDQ Board to the H4 header of the Docking Panel are typically not accessed directly, and are not discussed in detail here. Most computers conform to IBM PC AT-compatible RS232 interfaces which use 9-pin D-Type connectors, consequently the PDQ Board brings out its serial ports to two female 9-pin D-Type connectors on the Docking Panel. By default, the RS485 connections are not brought out to the Docking Panel’s DB-9 Serial1 Connector, although custom placement of zero-ohm surface-mount resistors on the Docking Panel can route the RS485 signals to the DB-9. These 9-pin standard DB-9 serial connectors are located on the back of the Docking Panel. The following table shows the connection diagram for a standard 9-pin serial cable. The PDQ Board’s transmit data signal /TxD1 (pin 2 on the 9-pin serial connector) is connected to the terminal’s receive data signal /RxD (pin 2 on its 9-pin connector).

If you do this now, remember to move the QScreen Controller’s serial connector back to Serial Port 1, and to change the terminal’s baud rate back to 19200 baud using the "Comm" item under the terminal’s "Settings" menu. Likewise, the terminal’s transmit signal /TxD is connected to the PDQ Board’s receive signal /RxD1. Although the RS232 protocol specifies functions for as many as 25 pins, each communications channel requires only three for simple serial interfaces: /TxD1 (transmit data), /RxD1 (receive data), and DGND (digital ground). The RS485 data direction of Serial1 and Serial2 are controlled by the PJ0 and PJ1 processor pins, respectively. It also defines three generator interface points (signal lines); A, B and C. The data is transmitted on A and B. C is a ground reference. It is important to note that when the CPHA bit is 0, the /SS line must be de-asserted and re-asserted between each successive data byte exchange (68HC11 Reference Manual, Section 8.3.2). If the CPHA bit is 1, the /SS line may be tied low between successive transfers. The above parity settings will also determine how incoming data is interpreted (whether the most significant bit is considered a parity bit or part of the data being transmitted, and how many bits total to expect in each byte).

Now select the "Comm" item in the "Settings" menu of the Terminal program, and click on 1200 baud (or whatever baud rate you selected in the command above). Once the project is open, click Build→ Build, and after the compilation is done, enter the Mosaic Terminal by clicking Tools→ Mosaic Terminal and use the Send File menu item to send GETSTART.DLF to the PDQ Board. Please contact Mosaic Industries if you need this custom configuration. The UART Wildcard implements these optional RS232 modem handshaking signals on channel 1. The handshaking signals can be disabled and/or ignored by applications that do not need them. Works with 4 AA batteries (1.5V, alkaline or Lithium - for outdoor winter use you need to use AA lithium batteries because the alkaline ones suffer from the cold); on request it is also available for working with external 5V power supply. The flexibility and power of the 68HC11’s serial peripheral interface supports high speed communication between the 68HC11 and other synchronous serial devices. The SCK pin’s synchronous clock signal has configurable phase, polarity and baud rate so that it can interface to a variety of synchronous serial devices.
